View bc546 bc547 bc548 datasheet:

JIANGSU CHANGJING ELECTRONICS TECHNOLOGY CO., LTD TO-92 Plastic-Encapsulate TransistorsBC546 / BC547 / BC548 TRANSISTOR (NPN)TO-92 FEATURES High Voltage Complement to BC556,BC557,BC5581. COLLECTOR 2. BASE 3. EMITTER BC546 BC547 BC548 Z XXX Z XXX Z XXX1 1 1Equivalent Circuit BC546,BC547,BC548=Device code Solid dot=Green molding compound device, if none,the normal deviceZ=Rank of hFE XXX=CodeORDERING INFORMATION Part Number Package Packing Method Pack Quantity BC546 TO-92 Bulk 1000pcs/BagBC546-TA TO-92 Tape 2000pcs/BoxBC547 TO-92 Bulk 1000pcs/BagBC547-TA TO-92 Tape 2000pcs/BoxBC548 TO-92 Bulk 1000pcs/BagBC548-TA TO-92 Tape 2000pcs/BoxMAXIMUM RATINGS (Ta=25 unless otherwise noted) Symbol Parameter Value Unit BC546 80V Collector-Base Voltage BC547 50 V CBOBC548 30BC546 65V Collector-Emitter Voltage
