View bc546 bc547 bc548 datasheet:

MOTOROLAOrder this documentSEMICONDUCTOR TECHNICAL DATAby BC546/DAmplifier TransistorsBC546, BNPN SiliconBC547, A, B, CBC548, A, B, CCOLLECTOR12BASE3EMITTER1MAXIMUM RATINGS23BC BC BC546 547 548Rating Symbol UnitCASE 2904, STYLE 17TO92 (TO226AA)CollectorEmitter Voltage VCEO 65 45 30 VdcCollectorBase Voltage VCBO 80 50 30 VdcEmitterBase Voltage VEBO 6.0 VdcCollector Current Continuous IC 100 mAdcTotal Device Dissipation @ TA = 25C PD 625 mWDerate above 25C 5.0 mW/CTotal Device Dissipation @ TC = 25C PD 1.5 WattDerate above 25C 12 mW/COperating and Storage Junction TJ, Tstg 55 to +150 CTemperature RangeTHERMAL CHARACTERISTICSCharacteristic Symbol Max UnitThermal Resistance, Junction to Ambient RqJA 200 C/WThermal Resistance, Junction to Case RqJC 83.3 C/WELECTRICAL CHARA
