View bc546 bc547 bc548 bc549 bc550 datasheet:

BC546/547/548/549/550Switching and Applications High Voltage: BC546, VCEO=65V Low Noise: BC549, BC550 Complement to BC556 ... BC560TO-9211. Collector 2. Base 3. EmitterNPN Epitaxial Silicon TransistorAbsolute Maximum Ratings Ta=25C unless otherwise noted Symbol Parameter Value UnitsVCBO Collector-Base Voltage : BC546 80 V: BC547/550 50 V: BC548/549 30 VVCEO Collector-Emitter Voltage : BC546 65 V: BC547/550 45 V: BC548/549 30 VVEBO Emitter-Base Voltage : BC546/547 6 V: BC548/549/550 5 VIC Collector Current (DC) 100 mAPC Collector Power Dissipation 500 mWTJ Junction Temperature 150 CTSTG Storage Temperature -65 ~ 150 CElectrical Characteristics Ta=25C unless otherwise noted Symbol Parameter Test Condition Min. Typ. Max. UnitsICBO Collector Cut-off Current VCB=30V, IE=0 15 nAhFE DC Current Gain VCE=5V, IC=2mA 110 800V
