View bc556abk bc557abk bc558abk bc559abk bc556bbk bc557bbk bc558bbk bc559bbk bc556cbk bc557cbk bc558cbk bc559cbk datasheet:

BC556xBK ... BC559xBKBC556xBK ... BC559xBKGeneral Purpose Si-Epitaxial PlanarTransistorsPNP PNPSi-Epitaxial Planar-Transistoren fr universellen EinsatzVersion 2009-12-070.1Power dissipation Verlustleistung 500 mW4.6Plastic case TO-92Kunststoffgehuse (10D3)Weight approx. Gewicht ca. 0.18 gC B EPlastic material has UL classification 94V-0Gehusematerial UL94V-0 klassifiziertSpecial packaging bulk2 x 1.27Sonder-Lieferform SchttgutDimensions - Mae [mm]Maximum ratings (T = 25C) Grenzwerte (T = 25C)A ABC556 BC557 BC558/559Collector-Emitter-voltage E-B short - V 80 V 50 V 30 VCESCollector-Emitter-voltage B open - V 65 V 45 V 30 VCEOCollector-Base-voltage E open - V 80 V 50 V 30 VCBOEmitter-Base-voltage C open - V 5 VEB0Power dissipation Verlustleistung P 500 mW 1)totCollector current Kollektorstrom
