View bc817 bc817w bc337 datasheet:
BC817; BC817W; BC33745 V, 500 mA NPN general-purpose transistorsRev. 06 17 November 2009 Product data sheet1. Product profile1.1 General descriptionNPN general-purpose transistors.Table 1. Product overviewType number Package PNP complementNXP JEITABC817 SOT23 - BC807BC817W SOT323 SC-70 BC807WBC337[1] SOT54 (TO-92) SC-43A BC327[1] Also available in SOT54A and SOT54 variant packages (see Section 2).1.2 Features High current Low voltage1.3 Applications General-purpose switching and amplification1.4 Quick reference dataTable 2. Quick reference dataSymbol Parameter Conditions Min Typ Max UnitVCEO collector-emitter voltage open base; - - 45 VIC =10mAIC collector current (DC) - - 500 mAICM peak collector current - - 1 A[1]hFE DC current gain IC = 100 mA; - - -VCE =1VBC817; BC817W; BC337 100 - 600BC817-16; BC817-16W; BC337-16 100 -
