View bd136g bd138g bd140g datasheet:
BD136G, BD138G, BD140GPlastic Medium-PowerSilicon PNP TransistorsThis series of plastic, medium-power silicon PNP transistors aredesigned for use as audio amplifiers and drivers utilizingcomplementary or quasi complementary circuits.www.onsemi.comFeatures High DC Current Gain1.5 A POWER TRANSISTORS BD 136, 138, 140 are complementary with BD 135, 137, 139PNP SILICON These Devices are Pb-Free, Halogen Free/BFR Free and are RoHS45, 60, 80 V, 12.5 WCompliant*COLLECTORMAXIMUM RATINGS2, 4Rating Symbol Value UnitCollector-Emitter Voltage VCEO Vdc3BD136G 45BASEBD138G 60BD140G 801Collector-Base Voltage VCBO VdcEMITTERBD136G 45BD138G 60BD140G 100Emitter-Base Voltage VEBO 5.0 VdcCollector Current IC 1.5 AdcTO-225Base Current IB 0.5 AdcCASE 77-09STYLE 1Total Device Dissipation PD@ TA = 25C 1.25 WattsDerate ab
