BD241ABD241CNPN power transistors.Features NPN transistorsApplications Audio, general purpose switching and amplifier transistors321DescriptionTO-220The devices are manufactured in Planar technology with Base Island layout. The resulting transistor shows exceptional high gain Figure 1. Internal schematic diagramperformance coupled with very low saturation voltage. The PNP types are BD242A and BD242C.Table 1. Device summaryOrder codes Marking Package PackagingBD241A BD241A TO-220 TubeBD241C BD241C TO-220 TubeJuly 2007 Rev 2 1/9www.st.com 9Absolute maximum ratings BD241A BD241C1 Absolute maximum ratingsTable 2. Absolute maximum ratingsValueSymbol Parameter UnitBD241A BD241CVCER Collector-emitter voltage (RBE = 100) 70 115 VVCEO Collector-emitter voltage (IB = 0) 60 100 VVEBO Emitter-base voltage (IC =
