Order this documentMOTOROLAby BD241C/DSEMICONDUCTOR TECHNICAL DATANPNBD241C*Complementary Silicon Plastic PNPBD242BPower Transistors. . . designed for use in general purpose amplifier and switching applications.BD242C* CollectorEmitter Saturation Voltage VCE = 1.2 Vdc (Max) @ IC = 3.0 Adc*Motorola Preferred Device CollectorEmitter Sustaining Voltage VCEO(sus) = 80 Vdc (Min.) BD242B3 AMPEREVCEO(sus) = 100 Vdc (Min.) BD241C, BD242CPOWER TRANSISTORS High Current Gain Bandwidth ProductCOMPLEMENTARYfT = 3.0 MHz (Min) @ IC = 500 mAdcSILICON Compact TO220 AB Package80, 100 VOLTS40 WATTSMAXIMUM RATINGSBD241C BD242B BD242CRating Symbol Unit
