View bdx33 a b c datasheet:

Inchange Semiconductor Product Specification Silicon NPN Power Transistors BDX33/A/B/C DESCRIPTION With TO-220C package High DC current gain DARLINGTON Complement to type BDX34/A/B/C APPLICATIONS For power linear and switching applications PINNING PIN DESCRIPTION1 Base Collector;connected to 2 mounting base 3 EmitterAbsolute maximum ratings(Ta=25) SYMBOL PARAMETER CONDITIONS VALUE UNITBDX33 45BDX33A 60 VCBO Collector-base voltage Open emitter V BDX33B 80 BDX33C 100 BDX33 45BDX33A 60 VCEO Collector-emitter voltage Open base V BDX33B 80 BDX33C 100 VEBO Emitter-base voltage Open collector 5 V IC Collector current-DC 10 AICM Collector current-Pulse 15 AIB Base current 0.25 APC Collector power dissipation TC=25 70 W Tj Junction temperature 150 Tstg Storage temperature -65~150 THERMAL CHARACTERIS
