View bf244a-b-c datasheet:

bf244a-b-cbf244a-b-c

BF244ABF244BBF244CS TO-92GDN-Channel RF AmplifierThis device is designed for RF amplifier and mixer applicationsoperating up to 450 MHz, and for analog switching requiring lowcapacitance. Sourced from Process 50.Absolute Maximum Ratings* TA = 25C unless otherwise notedSymbol Parameter Value UnitsVDG Drain-Gate Voltage 30 VVGS Gate-Source Voltage - 30 VID Drain Current 50 mAIGF Forward Gate Current 10 mAStorage Temperature Range -55 to +150T Cstg*These ratings are limiting values above which the serviceability of any semiconductor device may be impaired.NOTES:1) These ratings are based on a maximum junction temperature of 150 degrees C.2) These are steady state limits. The factory should be consulted on applications involving pulsed or low duty cycle operations.Thermal Characteristics TA = 25C unless otherwise notedSymbol Characteri
