BFR740EL3SiGe:C NPN RF bipolar transistorProduct descriptionThe BFR740EL3 is a wideband RF heterojunction bipolar transistor (HBT) available in alow profile package.Feature list Low noise figure NFmin = 0.5 dB at 1.9 GHz 3 V, 6 mA; 0.8 dB at 5.5 GHz, 3 V, 6 mA High power gain Gms = 20 dB at 5.5 GHz, 3 V, 15 mA Low profile and small form factor leadless package High sensitivity low noise laser receiver matrix High RF transistor hFE controllabilityProduct validationQualified for industrial applications according to the relevant tests of JEDEC47/20/22.Potential applications Wireless communications: WLAN 2.4 GHz and 5-6 GHz bands, WiMax and UWB Satellite communication systems: GNSS navigation systems (GPS, GLONASS, BeiDou, Galileo), satelliteradio (SDARs, DAB) and C-band LNB Multimedia applications such as portable TV, CATV and FM
