View bss138 datasheet:

BSS138www.VBsemi.twN-Channel 60-V (D-S) MOSFETFEATURESPRODUCT SUMMARY Halogen-free According to IEC 61249-2-21 VDS (V) RDS(on) ()ID (mA)Definition2.8 at VGS = 10 V60 250 Low Threshold: 2 V (typ.) Low Input Capacitance: 25 pF Fast Switching Speed: 25 ns Low Input and Output LeakageSOT-23 TrenchFET Power MOSFET 1200V ESD ProtectionG 1 Compliant to RoHS Directive 2002/95/EC3 D BENEFITSS 2 Low Offset Voltage Low-Voltage OperationTop View Easily Driven Without Buffer High-Speed Circuits Low Error VoltageDAPPLICATIONS Direct Logic-Level Interface: TTL/CMOS Drivers: Relays, Solenoids, Lamps, Hammers, Display,GMemories, Transistors, etc. Battery Operated Systems Solid-State RelaysSN-Channel MOSFETABSOLUTE MAXIMUM RATINGS TA = 25 C, unless otherwise noted
