View bss138 datasheet:

BSS138 MOSFET(N-Channel)V(BR)DSS RDS(ON)MAX IDSOT-23 3.5@10V50V 0.22ASOT-23 Plastic-Encapsulate MOSFET6@4.5VSOT-23 Features TrenchFET Power MOSFET Load Switch for Portable Devices. DC/DC Converter. Mechanical Data : SOT-23 SOT-23 Small Outline Plastic Package. UL Epoxy UL: 94V-0. : Mounting Position: Any.(TA = 25 )Maximum Ratings & Thermal Characteristics (Ratings at 25 ambient temperature unless otherwise specified.) Parameters Symbol Value UnitDrain-Source Voltage VDS 50 VGate-Source Voltage VGS V20Continuous Drain Current ID 0.22 APower Dissipation PD 350 mWJunction Temperature Tj 150Storage Temperature Tstg -50-+150Thermal Re
