View bss138 datasheet:

SMD Type MOSFETN-Channel MOSFETBSS138 (KSS138)SOT-23Unit: mm+0.12.9 -0.1+0.10.4 -0.13 Features VDS (V) = 50V ID = 200 mA (VGS = 10V)1 2 RDS(ON) 3.5 (VGS = 10V)+0.1+0.050.95-0.1 0.1-0.01+0.1 Fast Switching Speed1.9-0.1 Low On-Resistance1. Gate2. Source3. Drain Absolute Maximum Ratings Ta = 25Parameter Symbol Rating Unit Drain-Source Voltage VDS 50V Drain-Gate Voltage RGS 20K VDG 50 Gate-Source Voltage VGS 20 Continuous Drain Current ID 200 mA Power Dissipation PD 300 mW Thermal Resistance.Junction- to-Ambient RthJA 417 /W Junction Temperature TJ 150 Storage Temperature Range Tstg -55 to 150 Electrical Characteristics Ta = 25Parameter Symbol Test Conditions Min Typ Max Unit Drain-Source Breakdown Voltage VDSS ID=250A, VGS=0V 50 V Zero Gate Voltage Drain
