View bss138 datasheet:

BSS138Features High Dense Cell Design for Extremely Low RDS(ON) Voltage Controlled Small Signal Switch Surface Mount Package Epoxy Meets UL 94 V-0 Flammability RatingN-Channel MOSFET Moisture Sensitivity Level 1 Halogen Free Available Upon Request By Adding Suffix "-HF" Lead Free Finish/RoHS Compliant ("P" Suffix Designates RoHSCompliant. See Ordering Information)Maximum Ratings Operating Junction Temperature Range: -55C to +150CSOT-23 Storage Temperature: -55C to +150C Thermal Resistance: 357C/W Junction to AmbientAParameter Symbol Rating UnitDDrain-Source Voltage VDS 50 VBCGate-Source Voltage VGS 20 VID 0.22 ADrain Current-ContinuousF EPower Dissipation PD 0.35 WG H JLKDIMENSIONSINCHES MMInternal StructureDIM NOTEMIN MAX MIN MAXD A 0.110 0.120 2.80 3.04B 0.083 0.104 2.10
