View bss138aka datasheet:

BSS138AKA60 V, single N-channel Trench MOSFET29 April 2015 Product data sheet1. General descriptionN-channel enhancement mode Field-Effect Transistor (FET) in a small SOT23(TO-236AB) Surface-Mounted Device (SMD) plastic package using Trench MOSFETtechnology.2. Features and benefits Very fast switching Trench MOSFET technology ESD protection Low threshold voltage AEC-Q101 qualified3. Applications Relay driver High-speed line driver Low-side loadswitch Switching circuits4. Quick reference dataTable 1. Quick reference dataSymbol Parameter Conditions Min Typ Max UnitVDS drain-source voltage Tj = 25 C - - 60 VVGS gate-source voltage -20 - 20 VID drain current VGS = 10 V; Tamb = 25 C [1] - - 200 mAStatic characteristicsRDSon drain-source on-state VGS = 10 V; ID = 100 mA; pulsed; - 2.7 4.5 resistancetp
