View bss138dw datasheet:

BSS138DWwww.VBsemi.twDual N-Channel 60 V (D-S) MOSFETPRODUCT SUMMARY FEATURESVDS (V) RDS(on) ()ID (mA) Halogen-free According to IEC 61249-2-21 Definition2.5 at VGS = 10 V60 300Low On-Resistance:2.5 Low Threshold: 2 V (typ.) Low Input Capacitance: 25 pF Fast Switching Speed: 25 nsSOT-363 Low Input and Output LeakageSC-70 TrenchFET Power MOSFET Compliant to RoHS Directive 2002/95/ECS 1 1 6 D 1 5 G 1 2 G 2 BENEFITS Low Offset VoltageD 2 3 4 S 2 Low-Voltage Operation Easily Driven Without BufferTop View High-Speed Circuits Low Error VoltageD1 D2APPLICATIONS Direct Logic-Level Interface: TTL/CMOS Drivers: Relays, Solenoids, Lamps, Hammers, Display,G1 G2Memories, Transistors, etc. Battery Operated Systems Solid-State RelaysS1 S2ABSOLUTE MAXIMUM RATINGS
