View bss138w datasheet:

BSS138Wwww.VBsemi.twN-Channel 60-V (D-S) MOSFETFEATURESPRODUCT SUMMARY Halogen-free According to IEC 61249-2-21 VDS (V) RDS(on) ()ID (mA)Definition2 at VGS = 10 V60 300 Low On-Resistance: 2 Low Threshold: 2 V (typ.) Low Input Capacitance: 25 pF Fast Switching Speed: 25 nsSOT-323 Low Input and Output LeakageSC-70 (3-LEADS) TrenchFET Power MOSFET 1200V ESD ProtectionG1 Compliant to RoHS Directive 2002/95/EC3 DBENEFITS Low Offset VoltageS 2 Low-Voltage Operation Easily Driven Without BufferTop View High-Speed Circuits Low Error VoltageDrainAPPLICATIONS Direct Logic-Level Interface: TTL/CMOS Drivers: Relays, Solenoids, Lamps, Hammers, Display,Memories, Transistors, etc.Gate Battery Operated Systems Solid-State RelaysSourceABSOLUTE MAXIMUM RATINGS TA
