View bss138w datasheet:

BSS138W3 DRAINN-Channel POWER MOSFETP b Lead(Pb)-Free3121Description:GATE* Typical applications are dcdc converters, SOT-323(SC-70) power management in portable and batterypowered2 SOURCE products such as computers, printers, PCMCIA cards, cellular and cordless telephones.Features:* Simple Drive Requirement* Small Package OutlineMaximum Ratings (TA=25C Unless Otherwise Specified)Rating Symbol Value UnitDrain-Source Voltage VDS 50 VGate-Source Voltage VGS 20 VContinuous Drain CurrentID 200 mAVGS = (TA=25C)IDM mA800Pulsed Drain Current (tp 10S)Power Dissipation (TA=25C) PD 150 mWRJA556 C/WMaximax Junction-to-AmbientOperating Junction Temperature Range CTJ +150Storage Temperature Range CTstg -55 to +150Maximum Lead Temperature for SolderingTL260 CPurposes, for 10 secondsDevi
