View btd882j3 datasheet:

btd882j3btd882j3

Spec. No. : C848J3-H Issued Date : 2003.04.02 CYStech Electronics Corp.Revised Date :2013.03.12 Page No. : 1/7 Low Vcesat NPN Epitaxial Planar TransistorBVCEO 50VIC 3ABTD882J3RCESAT (Typ) 125m Features Low VCE(sat), typically 0.25V at IC / IB = 2A / 0.2A Excellent current gain characteristics Complementary to BTB772J3 Pb-free package Symbol Outline BTD882J3 TO-252(DPAK) BBase CCollector EEmitter B C E Absolute Maximum Ratings (Ta=25C) Parameter Symbol Limit UnitCollector-Base Voltage VCBO 40 VCollector-Emitter Voltage VCEO 30 VEmitter-Base Voltage VEBO 5 VIC(DC) 3 ACollector Current IC(Pulse) 7 *1 A Pd(Ta=25) 1Power Dissipation W Pd(Tc=25) 10Junction Temperature Tj 150 C Storage Temperature Tstg -55~+150 C Note : *1. Single Pulse Pw350us,Duty2%. BTD882J3 CYStek Product
