View bu208a bu508a bu508afi datasheet:

BU208ABU508A/BU508AFIHIGH VOLTAGE FAST-SWITCHINGNPN POWER TRANSISTORS STMicroelectronics PREFERREDSALESTYPES HIGH VOLTAGE CAPABILITY (> 1500 V) FULLY INSULATED PACKAGE (U.L.TO-3COMPLIANT) FOR EASY MOUNTING1APPLICATIONS: 2 HORIZONTAL DEFLECTION FOR COLOURTV DESCRIPTION The BU208A, BU508A and BU508AFI aremanufactured using Multiepitaxial Mesa33technology for cost-effective high performance22and use a Hollow Emitter structure to enhance 1 1TO-218 ISOWATT218switching speeds.INTERNAL SCHEMATIC DIAGRAMFor TO-3 :C = TabE = Pin2.ABSOLUTE MAXIMUM RATINGSSymbol Parameter Value UnitVCES Collector-Emitter Voltage (VBE = 0) 1500 VVCEO Collector-Emitter Voltage (IB = 0) 700 VVEBO Emitter-Base Voltage (IC = 0) 10 VIC Collector Current 8 AICM Collector Peak Current (tp
