View bu208d bu508d datasheet:

BU208D/508D/508DFIHIGH VOLTAGE FASTSWITCHING NPNPOWER TRANSISTOR SGS-THOMSON PREFERRED SALESTYPES HIGH VOLTAGE CAPABILITY U.L. RECOGNISED ISOWATT218 PACKAGE(U.L. FILE # E81734 (N)TO-3 JEDEC TO-3 METAL CASE NPN TRANSISTOR WITH INTEGRATED1FREEWHEELING DIODE2APPLICATIONS: HORIZONTAL DEFLECTION FOR COLOURTVDESCRIPTION33The BU208D, BU508D and BU508DFI are22manufactured using Multiepitaxial Mesa 1 1TO-218 ISOWATT218technology for cost-effective high performanceand uses a Hollow Emitter structure to enhanceswitching speeds.INTERNAL SCHEMATIC DIAGRAMABSOLUTE MAXIMUM RATINGSSymbol Parameter Value UnitV Collector-Emitter Voltage (V = 0) 1500 VCES BEVCEO Collector-Emitter Voltage (IB = 0) 700 VVEBO Emitter-Base Voltage (IC = 0) 10 VI Collector Current 8 ACI Collector Peak Current (t
