View bu508a datasheet:

BU208A/508A/508AFIHIGH VOLTAGE FAST-SWITCHINGNPN POWER TRANSISTOR SGS-THOMSON PREFERRED SALESTYPES HIGH VOLTAGE CAPABILITY U.L. RECOGNISED ISOWATT218 PACKAGE(U.L. FILE # E81734 (N)TO-3 JEDEC TO-3 METAL CASE.1APPLICATIONS:2 HORIZONTAL DEFLECTION FOR COLOURTVDESCRIPTIONThe BU208A, BU508A and BU508AFI aremanufactured using Multiepitaxial Mesa33technology for cost-effective high performance221 1and uses a Hollow Emitter structure to enhanceTO-218 ISOWATT218switching speeds.INTERNAL SCHEMATIC DIAGRAMABSOLUTE MAXIMUM RATINGSSymbol Parameter Value UnitV Collector-Emitter Voltage (V = 0) 1500 VCES BEVCEO Collector-Emitter Voltage (IB = 0) 700 VV Emitter-Base Voltage (I = 0) 10 VEBO CIC Collector Current 8 AICM Collector Peak Current (tp
