View bu508af datasheet:
BU508AFHigh voltage NPN power transistor for standarddefinition CRT displayFeatures State-of-the-art technology: Diffused collector Enhanced generation Stable performances versus operating temperature variation Low base-drive requirement32 Tight hFE range at operating collector current1 High ruggednessISOWATT218FX Fully insulated power package U.L. compliantApplications Horizontal deflection output for CRT TVFigure 1. Internal schematic diagram Switch mode power supplies for CRT TVDescriptionThe BU508AF is manufactured using diffused collector in planar technology adopting new and enhanced high voltage structure for updated performance to the horizontal deflection stage.Table 1. Device summaryOrder code Marking Package PackagingBU508AF BU508AF ISOWATT218FX TubeAugust 2007 Rev 2 1/11www.st.com 11
