Inchange Semiconductor Product Specification Silicon NPN Power Transistors BU508D DESCRIPTION With TO-3PN package High voltage Built-in damper diode APPLICATIONS For use in large screen colour deflection circuits. PINNING PIN DESCRIPTION1 Base Collector;connected to 2 mounting base Fig.1 simplified outline (TO-3PN) and symbol 3 Emitter Absolute maximum ratings (Ta=25) SYMBOL PARAMETER CONDITIONS VALUE UNITVCBO Collector-base voltage Open emitter 1500 V VCEO Collector-emitter voltage Open base 700 V VEBO Emitter-base voltage Open collector 5 V IC Collector current (DC) 5 A ICM Collector current (Pulse) 8 A IB Base current 2.5 APC Collector power dissipation TC=25 125 WTj Junction temperature 150 Tstg Storage temperature -65-150 THERMAL CHARACTERISTICS SYMBOL PARAMETER VALUE UNITRth j-c Thermal resista
