View bu508dfi datasheet:

BU508DFIHIGH VOLTAGE FAST-SWITCHINGNPN POWER TRANSISTOR STMicroelectronics PREFERREDSALESTYPE HIGH VOLTAGE CAPABILITY ( > 1500 V ) NPN TRANSISTOR WITH INTEGRATEDFREEWHEELING DIODE FULLY INSULATED PACKAGE (U.L.COMPLIANT) FOR EASY MOUNTINGAPPLICATIONS: 3 HORIZONTAL DEFLECTION FOR COLOUR2TV UP TO 25"1DESCRIPTION ISOWATT218The BU508DFI is manufactured usingMultiepitaxial Mesa technology for cost-effectivehigh performance and uses a Hollow Emitterstructure to enhance switching speeds.INTERNAL SCHEMATIC DIAGRAMABSOLUTE MAXIMUM RATINGSSymbol Parameter Value UnitV Collector-Emitter Voltage (V = 0) 1500 VCES BEVCEO Collector-Emitter Voltage (IB = 0) 700 VVEBO Emitter-Base Voltage (IC = 0) 10 VIC Collector Current 8 AICM Collector Peak Current (tp
