View buz110sl datasheet:
BUZ 110SLSIPMOS Power TransistorProduct SummaryFeaturesDrain source voltage 55 VVDS N channelDrain-Source on-state resistance 0.01RDS(on) Enhancement modeContinuous drain current 80 AID Avalanche rated Logic Level dv/dt rated 175C operating temperaturePin 1 Pin 2 Pin 3Type Package Ordering Code PackagingG D SBUZ110SL P-TO220-3-1 Q67040-S4004-A2 TubeBUZ110SL E3045A P-TO263-3-2 Q67040-S4004-A6 Tape and ReelBUZ110SL E3045 P-TO263-3-2 Q67040-S4004-A5 TubeMaximum Ratings, at Tj = 25 C, unless otherwise specifiedParameter Symbol Value UnitContinuous drain current AIDTC = 25 C 80 TC = 100 C 59Pulsed drain current 320IDpulseTC = 25 CAvalanche energy, single pulse 460 mJEASID = 80 A, VDD = 25 V, RGS = 25 20 Avalanche energy, periodic limited by Tjmax EAR6 kV/sReverse diode dv/dt dv
