View cdl13007ddl datasheet:

Continental Device India LimitedAn ISO/TS 16949, ISO 9001 and ISO 14001 Certified CompanyNPN PLASTIC POWER TRANSISTORCDL13007DTO-220Plastic PackageBuilt in DiodeABSOLUTE MAXIMUM RATINGS DESCRIPTION SYMBOL VALUE UNITCollector Base Voltage VCBO 700 VVCEOCollector Emitter Voltage 400 VVEBOEmitter Base Voltage 9 VICCollector Current Continuous 7 ACollector Power Dissipation Tc=25C PC 80 WTjJunction Temperature 150 CStorage Temperature Range Tstg - 55 to +150 CELECTRICAL CHARACTERISTICS (Tc=25C unless specified otherwise)DESCRIPTION SYMBOL TEST CONDITION MIN TYP MAX UNITCollector Cut Off Current ICBO VCB=700V, IE=0 100 AEmitter Cut Off Current IEBO VEB=9V, IC=0 100 ADC Current Gain hFE IC=2A, VCE=5V 15 35Collector Emitter Saturation Voltage VCE (sat) IC=5A, IB=1A 1.0 VBase Emitter Saturation Voltage VBE (sat) IC=5A, IB=1A 1.5
