View cem3307 datasheet:

CEM3307www.VBsemi.twDual P-Channel 30-V (D-S) MOSFETFEATURESPRODUCT SUMMARY Halogen-freeVDS (V) RDS(on) ()ID (A)d, e Qg (Typ.) TrenchFET Power MOSFET0.029 at VGS = - 10 V - 7.3 100 % UIS TestedRoHS- 30 17 nCCOMPLIANT0.039 at VGS = - 4.5 V - 6.3APPLICATIONS Load SwitchesS1 S2SO-8S1 1 D18G1 G2G1 2 D17S2 3 D26G2 4 D25Top ViewD1 D2P-Channel MOSFET P-Channel MOSFETABSOLUTE MAXIMUM RATINGS TA = 25 C, unless otherwise notedParameter Symbol Limit UnitVDSDrain-Source Voltage - 30VVGSGate-Source Voltage 20TC = 25 C- 7.3eTC = 70 C- 7.0eContinuous Drain Current (TJ = 150 C) IDTA = 25 C - 7.3a, bTA = 70 C - 5.9a, bAIDM- 32ePulsed Drain Current- 4.1TC = 25 CISContinuous Source-Drain Diode CurrentTA = 25 C - 2.0a, bIASAvalanche Current - 20L = 0.1 mHEA
