CEM4228Dual N-Channel Enhancement Mode Field Effect TransistorFEATURES540V, 6.3A, RDS(ON) = 30m @VGS = 10V. RDS(ON) = 45m @VGS = 4.5V.Super high dense cell design for extremely low RDS(ON).High power and current handing capability.D1 D1 D2 D2Lead free product is acquired.8 7 6 5Surface mount Package.SO-81 2 3 41S1 G1 S2 G2ABSOLUTE MAXIMUM RATINGS TA = 25 C unless otherwise notedParameter Symbol Limit UnitsDrain-Source Voltage VDS 40 VGate-Source Voltage VGS 20 VDrain Current-Continuous ID 6.3 ADrain Current-Pulsed a IDM 20 AMaximum Power Dissipation PD 2.0 WOperating and Store Temperature Range TJ,Tstg -55 to 150 CThermal CharacteristicsParameter Symbol Limit UnitsThermal Resistance, Junction-to-Ambient b RJA 62.5 C/WRev 1. 2006.MarchSpecification and data are subject to change without notice . http://www.cetsemi.com
