View cep85n75 ceb85n75 cef85n75 datasheet:

CEP85N75/CEB85N75CEF85N75N-Channel Enhancement Mode Field Effect TransistorFEATURESType VDSS RDS(ON) ID @VGSCEP85N75 75V 12m 86A 10VCEB85N75 75V 12m 86A 10VCEF85N75 75V 12m 86A e 10VDSuper high dense cell design for extremely low RDS(ON).High power and current handing capability.Lead free product is acquired.TO-220 & TO-263 package & TO-220F full-pak for through hole.GSCEB SERIES CEP SERIES CEF SERIESTO-263(DD-PAK) TO-220 TO-220FABSOLUTE MAXIMUM RATINGS Tc = 25 C unless otherwise notedLimitParameter Symbol UnitsTO-220/263 TO-220FDrain-Source Voltage VDS 75 VGate-Source Voltage VGS V30Drain Current-Continuous ID 86 86e ADrain Current-Pulsed a IDM f 344 344e AMaximum Power Dissipation @ TC = 25 C 200 75 WPD- Derate above 25 C 1.33 0.5 W/ CSingle Pulsed Avalanche Energy d EAS 880 880 mJSingle Pulsed Avalanche Current
