View chm4301zgp datasheet:

CHENMKO ENTERPRISE CO.,LTDCHM4301ZGPSURFACE MOUNT P-Channel Enhancement Mode Field Effect Transistor VOLTAGE 40 Volts CURRENT 6.3 AmpereAPPLICATION* Servo motor control. * Power MOSFET gate drivers.* Other switching applications.SC-73/SOT-223FEATURE* Small flat package. ( SC-73/SOT-223 )1.65+0.15* High density cell design for extremely low RDS(ON). 6.50+0.200.90+0.052.0+0.33.00+0.10* Rugged and reliable.* High saturation current capability.CONSTRUCTION0.9+0.2* P-Channel Enhancement 0.70+0.10 0.27+0.050.01~0.10 0.70+0.10 0.70+0.102.30+0.14.60+0.113 21 GateD2 Source3CIRCUIT3 Drain ( Heat Sink )1GDimensions in millimeters SC-73/SOT-2232SAbsolute Maximum Ratings TA = 25C unless otherwise notedSymbol Parameter CHM4301ZGP UnitsVDSS Drain-Source Voltage -40 VVGSS Gate-Source Voltage20 VMaxim
