View cht847bvgp datasheet:

CHENMKO ENTERPRISE CO.,LTDCHT847BVGPSURFACE MOUNT NPN General Purpose TransistorVOLTAGE 45 Volts CURRENT 0.1 AmpereAPPLICATION* AF input stages and driver applicationon equipment.* Other general purpose applications.FEATURESOT-563* Small surface mounting type. (SOT-563)* High current gain. * Suitable for high packing density.* Low colloector-emitter saturation.(1)(5)* High saturation current capability.0.500.9~1.1 1.5~1.70.50CONSTRUCTION(4)(3)0.15~0.3* Two NPN transistors in one package.1.1~1.3MARKING* V30.5~0.60.09~0.18C1 B2 E26 5 4CIRCUIT 1.5~1.7TR2TR11 2 3Dimensions in millimeters SOT-563E1 B1 C2LIMITING VALUESIn accordance with the Absolute Maximum Rating System (IEC 60134).SYMBOL PARAMETER CONDITIONS UNITVCBO collector-base voltageopen emitter 50 VVCEO Vcollector-emitter voltage open base 45
