View chta42zgp datasheet:
CHENMKO ENTERPRISE CO.,LTDCHTA42ZGPSURFACE MOUNT NPN SILICON Transistor VOLTAGE 300 Volts CURRENT 0.5 AmpereAPPLICATION* Telephony and proferssional communction equipment.* Other switching applications.SC-73/SOT-223FEATURE* Small flat package. ( SC-73/SOT-223 )* Suitable for high packing density.1.65+0.156.50+0.200.90+0.052.0+0.33.00+0.10CONSTRUCTION*NPN SILICON Transistor0.9+0.2 0.70+0.10 0.27+0.05MARKING0.01~0.10 0.70+0.10 0.70+0.102.30+0.1ZHN4.60+0.113 21 Base2 EmitterC (3)CIRCUIT3 Collector ( Heat Sink )(1) BE(2)Dimensions in millimeters SC-73/SOT-223LIMITING VALUESIn accordance with the Absolute Maximum Rating System (IEC 60134).SYMBOL PARAMETER CONDITIONS MIN. MAX. UNITVCBO collector-base voltage open emitter - 300 VVCEO collector-emitter voltage open base - 300 VVEBO emitter-base voltage open
