View chumb11gp datasheet:
CHENMKO ENTERPRISE CO.,LTDCHUMB11GPSURFACE MOUNT Dual Digital Silicon TransistorVOLTAGE 50 Volts CURRENT 50 mAmpereAPPLICATION* Switching circuit, Inverter, Interface circuit, Driver circuit.FEATURE* Small surface mounting type. (SC-88/SOT-363)SC-88/SOT-363* High current gain. * Suitable for high packing density.* Low colloector-emitter saturation.* High saturation current capability. (4) (3)* Two CHDTA114E chips in a package.(5) 0.65* Built in bias resistor(R1=10k, Typ. ) 1.30.1 2.00.2(2)0.65(6)(1)0.10.20.051.250.10.150.05 0.90.10.70.10~0.10.1 Min.6 42.30.15CIRCUITR1 R2R2 R11 3 SC-88/SOT-363Dimensions in millimetersLIMITING VALUESIn accordance with the Absolute Maximum Rating System (IEC 60134).SYMBOL PARAMETER CONDITIONS MIN. MAX. UNITVCC Supply voltage - -50 VVIN Input voltage -40 +
