View chumg6gp datasheet:
CHENMKO ENTERPRISE CO.,LTDCHUMG6GPSURFACE MOUNTDual Digital Silicon TransistorVOLTAGE 50 Volts CURRENT 100 mAmpereAPPLICATION* Switching circuit, Inverter, Interface circuit, Driver circuit.FEATURE* Small surface mounting type. (SC-88A/SOT-353)SC-88A/SOT353* High current gain. * Suitable for high packing density.* Low colloector-emitter saturation.* High saturation current capability. (4) (3)* Both the CHDTC144T in one package.0.50* Built in bias resistor(R1=47k, Typ. ) 0.9~1.1 1.5~1.70.50(5) (1)0.15~0.31.1~1.30.5~0.60.19~0.181.5~1.73 2 1CIRCUITR1 R14 5 Dimensions in millimeters SOT553LIMITING VALUESIn accordance with the Absolute Maximum Rating System (IEC 60134).VALUESYMBOL PARAMETER CONDITIONS UNITVCBO Collector-Base voltage 50VVCEO Collector-Emitter voltage 50 VVEBO Emitter-Base voltage 5 VIC(Max.) Collec
