View chumh2gp datasheet:

chumh2gpchumh2gp

CHENMKO ENTERPRISE CO.,LTDCHUMH2GPSURFACE MOUNTDual Digital Silicon TransistorVOLTAGE 50 Volts CURRENT 30 mAmpereAPPLICATION* Switching circuit, Inverter, Interface circuit, Driver circuit.FEATURE* Small surface mounting type. (SC-88/SOT-363)SC-88/SOT-363* High current gain. * Suitable for high packing density.* Low colloector-emitter saturation.* High saturation current capability. (1) (6)* Two CHDTC144E transistors in one package.0.65* Built in bias resistor(R1=47k, Typ. ) 1.2~1.4 2.0~2.20.65(3) (4)0.15~0.351.15~1.350.08~0.15 0.8~1.10~0.10.1 Min.3 12.15~2.45CIRCUITR1 R2R2 R14 6Dimensions in millimeters SC-88/SOT-363LIMITING VALUESIn accordance with the Absolute Maximum Rating System (IEC 60134).SYMBOL PARAMETER CONDITIONS MIN. MAX. UNITVCC Supply voltage - 50 VVIN Input voltage -10 +40 VIO - 30DC Output c
