View chumh5gp datasheet:

chumh5gpchumh5gp

CHENMKO ENTERPRISE CO.,LTDCHUMH5GPSURFACE MOUNT NPN Digital Silicon TransistorVOLTAGE 50 Volts CURRENT 30 mAmpereAPPLICATION* Switching circuit, Inverter, Interface circuit, Driver circuit.FEATURE* Small surface mounting type. (SC-88/SOT-363)SC-88/SOT-363* High current gain. * Suitable for high packing density.* Low colloector-emitter saturation.* High saturation current capability. (4) (3)* two CHDTC124E chips in one package.(5) 0.65* Built in bias resistor(R1=22k, Typ. ) 1.30.1 2.00.2(2)0.65CONSTRUCTION (6)(1)0.10.20.05* One NPN transistors and bias of thin-film resistors in one1.250.1 package.0.150.05 0.90.10.70.10~0.10.1 Min.6 42.30.15CIRCUITR1R2R1R21 3Dimensions in millimeters SC-88/SOT-363LIMITING VALUESIn accordance with the Absolute Maximum Rating System (IEC 60134).SYMBOL
