CSD16327Q3www.ti.com SLPS371 DECEMBER 2011N-Channel NexFET Power MOSFETCheck for Samples: CSD16327Q31FEATURESPRODUCT SUMMARY2 Optimized for 5V Gate DriveVDS Drain to Source Voltage 25 V Ultra Low Qg and QgdQg Gate Charge Total (4.5V) 6.2 nC Low Thermal ResistanceQgd Gate Charge Gate to Drain 1.1 nCVGS = 3V 5 m Avalanche RatedRDS(on) Drain to Source On Resistance VGS = 4.5V 4 Pb Free Terminal PlatingVGS = 8V 3.4 RoHS CompliantVth Threshold Voltage 1.2 V Halogen Free SON 3.3mm x 3.3mm Plastic PackageORDERING INFORMATIONDevice Package Media Qty ShipAPPLICATIONSSON 3.3 3.3 13-inch Tape andCSD16327Q3 2500Plastic Package reel Reel Point-of-Load Synchronous Buck Converterfor Applications in Networking, Telecom andABSOLUTE MAXIMUM RATINGSComputing SystemsTA = 25C unless otherwise stated
