View csd16406q3 datasheet:

CSD16406Q3www.ti.com SLPS202A AUGUST 2009 REVISED SEPTEMBER 2010N-Channel NexFET Power MOSFETsCheck for Samples: CSD16406Q31FEATURESPRODUCT SUMMARY2 Ultra Low Qg and QgdVDS Drain to Source Voltage 25 V Low Thermal ResistanceQg Gate Charge Total (4.5V) 5.8 nC Avalanche RatedQgd Gate Charge Gate to Drain 1.5 nC Pb Free Terminal PlatingVGS = 4.5V 5.9 mRDS(on) Drain to Source On ResistanceVGS = 10V 4.2 m RoHS CompliantVth Threshold Voltage 1.8 V Halogen Free SON 3.3mm x 3.3mm Plastic PackageORDERING INFORMATIONDevice Package Media Qty ShipAPPLICATIONSSON 3.3 3.3 13-inch Tape andCSD16406Q3 2500 Point-of-Load Synchronous Buck ConverterPlastic Package reel Reelfor Applications in Networking, Telecom andComputing SystemsABSOLUTE MAXIMUM RATINGS Optimized for Control or Synchronous FET
