View csd16570q5b datasheet:

Sample & Support &Product Technical Tools &Buy CommunityFolder Documents SoftwareCSD16570Q5BSLPS496 JULY 2014CSD16570Q5B 25-V N-Channel NexFET Power MOSFET1 FeaturesProduct Summary1 Extremely Low ResistanceTA = 25C TYPICAL VALUE UNIT Low Qg and QgdVDS Drain-to-Source Voltage 25 V Low Thermal ResistanceQg Gate Charge Total (4.5 V) 95 nC Avalanche Rated Qgd Gate Charge Gate-to-Drain 31 nCVGS = 4.5 V 0.68 m Pb Free Terminal PlatingRDS(on) Drain-to-Source On-ResistanceVGS = 10 V 0.49 m RoHS CompliantVGS(th) Threshold Voltage 1.5 V Halogen Free SON 5-mm 6-mm Plastic PackageOrdering Information(1)Device Qty Media Package Ship2 ApplicationsCSD16570Q5B 2500 13-Inch ReelSON 5 6 mm Tape and ORing and Hot Swap Applications Plastic Package ReelCSD16570Q5BT 250 7-Inch Reel(1) For all ava
