View ctm2n7002 datasheet:

CTM2N7002Crownpo TechnologySmall Signal MOSFETFeatures General DescriptionHigh Density Cell Design for Low RDS(ON)This N-Channel enhancement mode field effect transistorVoltage Controlled Small Signal Switchis produced using high cell density,DMOS technology.TheseRugged and Reliableproducts have been designed to minimize on-stateHigh Saturation Current Capabilityresistance while provide rugged,reliable, and fast switchingperformance. It can be used in most applications requiringup to 115mA DC and can deliver pulsed currents up to800mA. This product is particularly suited for low voltage,low current applications such as small servo motor control,power MOSFET gate drivers, and other switchingapplications.Pin Configuration SymbolSOT-23 DTop View 3GS1 2N-Channel MOSFETOrdering InformationPart Number PackagePart Number PackageCTM2
