View dgf15n60ctl0 datasheet:

RoHS DGF15N60CTL0 COMPLIANT IGBT Discrete V 600 V CEI 15 A CV I = A 1.65 V CE(SAT) C 15 Applications Circuit Soft switching applications Air conditioning Motor drive inverter Features High speed smooth switching device for hard & soft switching Maximum junction temperature 175 Positive temperature coefficient High ruggedness, temperature stable Pb-free lead plating; RoHS compliant Maximum Ratings Parameter Symbol Value Unit V 600 V CECollector-Emitter Breakdown Voltage DC Collector Current, limited by T jmax30 T = 25C C15 I A C T = 100C CDiode Forward Current, limited by T jmaxT = 25C C 30 I A F 15 T = 100C CVGE 20 V Continuous Gate-Emitter Voltage VGE 30 V Transient Gate-Emitter Voltage Turn off Safe Operating Area V 600V, CE60
