View fcp11n60f fcpf11n60f datasheet:

December 2008 TMSuperFETFCP11N60F/FCPF11N60F600V N-Channel MOSFETFeatures Description 650V @TJ = 150C SuperFETTM is, Fairchilds proprietary, new generation of highvoltage MOSFET family that is utilizing an advanced charge Typ. RDS(on) = 0.32balance mechanism for outstanding low on-resistance and Fast Recovery Type ( trr = 120ns) lower gate charge performance. Ultra Low Gate Charge (typ. Qg = 40nC) This advanced technology has been tailored to minimizeconduction loss, provide superior switching performance, and Low Effective Output Capacitance (typ. Cosseff.=95pF)withstand extreme dv/dt rate and higher avalanche energy. 100% avalanche tested Consequently, SuperFET is very suitable for various AC/DCpower conversion in switching mode operation for system RoHS Compliant miniaturization and higher efficiency.DG TO-220
