View fdd16an08a0 datasheet:

fdd16an08a0fdd16an08a0

May 2002FDD16AN08A0N-Channel UltraFET Trench MOSFET75V, 50A, 16mFeatures Applications rDS(ON) = 13m (Typ.), VGS = 10V, ID = 50A 42V Automotive Load Control Qg(tot) = 31nC (Typ.), VGS = 10V Starter / Alternator Systems Low Miller Charge Electronic Power Steering Systems Low Qrr Body Diode Electronic Valve Train Systems UIS Capability (Single Pulse and Repetitive Pulse) DC-DC converters and Off-line UPS Qualified to AEC Q101 Distributed Power Architectures and VRMs Primary Switch for 24V and 48V systemsFormerly developmental type 82660DRAIN (FLANGE)DGATEGSOURCETO-252AASFDD SERIESMOSFET Maximum Ratings TC = 25C unless otherwise noted Symbol Parameter Ratings UnitsVDSS Drain to Source Voltage 75 VVGS Gate to Source Voltage 20 VDrain Current50 AContinuous (TC
