View fdd24an06la0 f085 datasheet:
January 2009FDD24AN06LA0_F085 N-Channel Logic Level PowerTrench MOSFET60V, 36A, 24mFeatures Applications rDS(ON) = 20m (Typ.), VGS = 5V, ID = 36A Motor / Body Load Control Qg(tot) = 16nC (Typ.), VGS = 5V ABS Systems Low Miller Charge Powertrain Management Low QRR Body Diode Injection Systems UIS Capability (Single Pulse and Repetitive Pulse) DC-DC converters and Off-line UPS Qualified to AEC Q101 Distributed Power Architectures and VRMs RoHS Compliant Primary Switch for 12V and 24V systemsFormerly developmental type 83547DRAIN (FLANGE)DGATESOURCE GTO-252AASFDD SERIESMOSFET Maximum Ratings TC = 25C unless otherwise noted Symbol Parameter Ratings UnitsVDSS Drain to Source Voltage60 VVGS Gate to Source Voltage20 VDrain Current40 AContinuous (TC = 25oC, VGS = 10V) Con
