View fdd3672 f085 datasheet:
March 2011FDD3672_F085N-Channel UltraFET Trench MOSFET 100V, 44A, 28m ApplicationsFeatures DC/DC converters and Off-Line UPS Typ rDS(on) = 24m at VGS = 10V, ID = 44A Distributed Power Architectures and VRMs Typ Qg(10) = 24nC at VGS = 10V Primary Switch for 24V and 48V Systems Low Miller Charge Low Qrr Body Diode High Voltage Synchronous Rectifier Optimized efficiency at high frequencies UIS Capability (Single Pulse and Repetitive Pulse) Qualified to AEC Q101 RoHS Compliant FDD3672_F085 Rev. C 1 www.fairchildsemi.comFDD3672_F085N-Channel UltraFET Trench MOSFETMOSFET Maximum Ratings TC = 25C unless otherwise noted Symbol Parameter Ratings UnitsVDSS Drain to Source Voltage 100 VVGS Gate to Source Voltage 20 VDrain Current Continuous (TC
