View fdmc7200s datasheet:

fdmc7200sfdmc7200s

June 2014FDMC7200SDual N-Channel PowerTrench MOSFETs 30 V, 22 m, 10 m Features General DescriptionThis device includes two specialized N-Channel MOSFETs in a Q1: N-Channeldual power33 (3mm X 3mm MLP) package. The switch node has Max rDS(on) = 22 m at VGS = 10 V, ID = 6 Abeen internally connected to enable easy placement and routing of synchronous buck converters. The control MOSFET (Q1) and Max rDS(on) = 34 m at VGS = 4.5 V, ID = 5 Asynchronous MOSFET (Q2) have been designed to provide optimal power efficiency.Q2: N-Channel Max rDS(on) = 10 m at VGS = 10 V, ID = 8.5 AApplications Max rDS(on) = 13.5 m at VGS = 4.5 V, ID = 7.2 A Mobile Computing RoHS Compliant Mobile Internet Devices General Purpose Point of LoadBottomBottomVIND1VIN Q2 D15 4Pin 1VIND1GHSG1VIND16 37 2GNDS2GNDS2GND8 1S2
