View fdp18n50 fdpf18n50 fdpf18n50t datasheet:

fdp18n50_fdpf18n50_fdpf18n50tfdp18n50_fdpf18n50_fdpf18n50t

November 2013FDP18N50 / FDPF18N50 / FDPF18N50TN-Channel UniFETTM MOSFET500 V, 18 A, 265 mFeatures Description RDS(on) = 220 m (Typ.) @ VGS = 10 V, ID = 9 A UniFETTM MOSFET is Fairchild Semiconductors high voltageMOSFET family based on planar stripe and DMOS technology. Low Gate Charge (Typ. 45 nC)This MOSFET is tailored to reduce on-state resistance, and to Low Crss (Typ. 25 pF)provide better switching performance and higher avalancheenergy strength. This device family is suitable for switching 100% Avalanche Testedpower converter applications such as power factor correctionApplications(PFC), flat panel display (FPD) TV power, ATX and electroniclamp ballasts. LCD/LED/PDP TV Lighting Uninterruptible Power SupplyDGGDS GDSTO-220 TO-220FSAbsolute Maximum Ratings TC = 25C unless otherwise noted.FDPF18N50
