View fgb20n60sfd datasheet:

March 2015FGB20N60SFD600 V, 20 A Field Stop IGBTFeatures Applications High Current Capability Solar Inverter, UPS, Welder, PFC Low Saturation Voltage: VCE(sat) = 2.2 V @ IC = 20 AGeneral Description High Input Impedance Fast Switching : EOFF = 8 uJ/AUsing novel field stop IGBT technology, Fairchilds field stopIGBTs offer the optimum performance for solar inverter, UPS, RoHS Compliantwelder and PFC applications where low conduction and switch-ing losses are essential.CCOLLECTOR(FLANGE)GTO-263AB/D2-PAKEG C EAbsolute Maximum RatingsSymbol Description Ratings UnitVCES Collector to Emitter Voltage 600 VGate to Emitter Voltage 20VGES VTransient Gate-to-Emitter Voltage 30Collector Current @ TC = 25oC40 AICCollector Current @ TC = 100oC20 AICM (1) Pulsed Collector Current 60 A@ TC = 25oC Diode Forward Cu
